The switch board carries the components required for the automatic operation. Any time wanted between 15 minutes (min.) and 24 h(max.) can be switched on for the cleaning cycle by a special timer. For the remaining time in reverse position only 3 min. will be provided. All switching positions are affixed according to the actual operation conditions before delivery at side, they should not be changed without reinformation of the deliverer. Between the cleaning periods, furthermore before start of operation or plan stop there are additional switches/cleanings possible by use a pressure switch. For function control each cycle will be registered by a counting device. In any case, if the torque switch of the actuator starts the alarm, the drive system returns to the final position before. The automatic operation remains in the breakdown position up to the time the pressure switch will be manual reseted.
